Safety:
The discharge monitor deactivates
the fast speed
function when the voltage is low to prevent exhaustive
discharge.
- When the control shaft is released, a gas pressure
spring causes it to be pushed into the upper position.
Controls:
The multi function handle
head with exemplary
ergonomics provides optimum operator comfort and
safety. The operating buttons for lifting/lowering
and horn can be reached without hand changes.
Drive Motor:
0.3 kW permanent magnet motor with shunt wound
characteristics. Motor protection circuit for
terminal overload. Power transmission via two-stage
gear unit with high efficiency. Grease lubrication.
Mast:
The sturdy single mast permits optimum visibility
conditions.
Drive wheel:
Standard Polyurethane tires.
Drive wheel dia. 9.06" x 3.15" wide. Caster Fork
Over dia 5.91" x 1.97" wide; Straddle Legs dia.
5.51" x 1.97" wide, spring loaded, springing 0.59".
Load wheels:
Easily replaceable Polyurethane
tires dia. 3.35" x 2.76" wide.
|
Steering:
By means of long, low slung
safety handle. Low steering forces. Handle may be
swiveled through 180°
Brake:
Magnetic brake acting on
motor shaft, operated through the handle. Braking
position with handle pressed down and handle in
upright position with simultaneous interruption
of the main power circuit. Asbestos-free brake.
Construction:
The Swift is a four-wheel truck with a steerable
drive wheel, a supporting wheel and two load-bearing
wheels. Hoods that are easy to open provide easy
access to all units. The operating controls are
located in the control handle head.
Lifting and Lowering:
Hydraulically through high
pressure pump with powerful
1 kW series wound motor.
Forks:
Sturdy and torsion resistant
box forks.
Batteries:
2 x 12V/60 Ah, maintenance free. Standard build-in
micro processor controlled battery charger with
charge control light, compensating charge and
maintenance charge. Charging of the batteries
via any main socket (Alternating Current (AC)
120V).
|
